VanGaa ERS400G 400W Colorful LED Fixed Lens Profile Ellipsoidal Light

-Model: VanGaa ERS400G
-Light output power: white 400W, RGBWAL 100W
-Color: RGBWAL
-Beam angle: 14/19/26/36°
-CRI: 95Ra+
  • VanGaa ERS400G
  • VanGaa
  • VanGaa ERS400G
  • 2021-10-15
  • Selling

·This is a professional LED Fixed Lens Profile Spot Light. It uses high CRI and high power LED integrated lamp (COB lamp) as the light emitting element, with color correction and RDM function, adopting the United State ETC optical lenses. This light is saving energy and protecting environment, pure color temperature, it is a very suitable substitute of the traditional 750 profile light.


·High light efficiency, good color rendering, low glare value;

·Long lifespan, energy conservation, environmental protection;

·Linear dimmer by DMX signal, smoothly 0-100%;

·Silent, owns good cooling system by copper radiation and fan(within 18db);

·High CRI more than 95Ra.

Technical Specifications

Light Sources

·LED: 1pc 500W RGBAL 5in1 COB LED Lamp

·Lifespan: 500,000h

·Color: RGBAL color mixing

·CRI: more than 95Ra


·Beam angle: 19degree(14degree/26degree/36degree optional), fixed lens

·Gobo clip: 1pc gobo clip with steel gobo optional

·Dimmer: 0-100% linear dimmer

·Strobe: 1-25 times/second

Light Output

·Luminous flux: 25200 Lm

·Illuminance: 1280 Lux (4m 14° Red)

·Optimal projection distance: 4-50m


·Focus: Manual

·Gobo clip: Manual


·Control mode: DMX-512; Demo; Master/slave

·DMX channel: 12CH

·Display of control panel: digital LCD display

·DMX In/Out: 3P-XLR DMX In/Out(5P-XLR optional), DMX 512

Power Supply

·Related voltage: AC100V-240V, 50/60Hz

·Related power: 450W


·Body dimension: D690*W260*H217mm

·Net weight: 8.2kg

·Shell color: black/white

·Shell material: die-casting aluminum

Working Environment

·Working temperature: -20-40℃

·Cooling: Copper radiation and Fan

·Protection rating: IP20

Equipment Optional Configuration

·Gobo clip: 1pc gobo clip

·Gobo: steel gobo, Gobo size: inner diameter 60mm, outer diameter71.6mm

·Barn doors: 1 set barn doors

·Colored paper clip: 1 set colored paper

Standard Configuration Spare Part List

·Cable: 1pc 3-pin DMX cable, 1pc power cable with plug(America standard, Euro standard, or other standard)

·User manual: English version user manual

Optional Configuration Spare Parts List

·Clamps: different style clamps optional (choose from VanGaa homepage “Accessaries series”)

·Safety rope: different size safety ropes optional (choose from VanGaa homepage “Accessaries series”)


·Carton board box package size: 730*370*360mm(1pc/carton)

·N.W/G.W/V.W: 11kg/12kg/19.5kg

Selling Maintain Spare Parts List

·Iris: VanGaa ERS400G-Iris

·Gobo frame: VanGaa ERS400G-GF

·Color paper frame: VanGaa ERS400G-CF

·Switching power supply: VanGaa ERS400G-P

·LED lamp board: VanGaa ERS400G -L

·Main board: VanGaa ERS400G-M

·Drive board: VanGaa ERS400G-D

ERS200A detailsERS200A dimension

ERS200A lux chart
