LED Mini Outer Ring Running Effect Moving Spot Light


Gobowheel:1fixedgobowheel:8gobosplusblank
1rotatedgobowheel:6gobosplusblank,gobo
rotating360°
Prism:5facetsprismwithrotatedfunction
Focus:linearfocusfromclosetofar
Max temperature:104°F(40°C)
Datainput/output:3pinXLR-connection、anodesocket
Outsidesize:290*182*400mm
N.W:7.5kg
Availability:
Quantity:
  • LM160

  • VanGaa

1LM1602Swift 1925Z (4)5客户展会图

Features

·The light’s lighting function is controlled by DMX-512, very convenient;

·Using bead LED chips, pure color temperature, can realize 0-100% dimmer;

·The light body adopts outside frame design, the modeling is beautiful, installation very convenient, safe and reliable.

Technical Specifications

Light Sources

·LED: 1pc 160W white 6500K LED Lamp

·Lifespan: 50,000hours

Optics

·Color wheel: 7 colors + open

·Static gobo wheel: 8 gobos + blank

·Rotated gobo wheel: 6 gobos + blank, gobo rotating 360°

·Prism: 5 facets prism with rotated function

·Focus: linear focus from close to far

·Dimmer: 0~100% linear dimmer

Control

·DMX channel: 16CH

·Control mode: DMX-512, Demo mode, Manual

·Control panel: LCD display + 4 buttons

Movement

·Pan: 540degree, with pan fine adjustment, 16bit

·Tilt: 270degree, with tilt fine adjustment, 16bit

Power Supply

·Related voltage: AC100V-240V, 50/60Hz

·Power consumption: 180W

Construction

·Body dimension: D290*W182*H400mm

·Net weight: 7.5kg

·Shell color: black

·Housing material: ABS

Working Environment

·Working temperature: -25-40℃

·Max temperature: 104°F(40°C)

·Cooling: aluminum radiator and light body

·Protection rating: IP20

Spare Parts

·Cable: 1set DMX in and DMX out signal cable,  and 1set Power in and Power out power cable with plug [standard configuration]

·Data input/output: 3pin XLR-connection, anode socket

Package

·Carton board box package size: 650*450*190mm(1pc/carton) [c:18-01-02]

·N.W/G.W/V.W: 5.5kg/7kg/12kg
