Color Panel 1440G-B
VanGaa
Color Panel 1440G-B
2019-06-30
Selling
This light equips two color temperature high cri and brightness led chips, used vangaa linear dimmer technology, to realize the product can meet the strict request when the radio and television shooting. No flicker, smooth linear dimmer, no drawing line when filming. The light is very suitable for large-scale tv station, studio, multi-function room and other video places.
Features
The light’s lighting function is controlled by DMX-512, very convenient;
Using bead LED chips, pure color temperature, can realize 0-100% dimmer;
The light body adopts outside frame design, the modeling is beautiful, installation very convenient, safe and reliable.
Technical Specifications
Light Sources
LED: 480pcs 0.2W RGB 3in1 LED chips, 480pcs 0.2W 3200K warm white LED chips, 480pcs 0.2W 5600K cold white led chips
Lifespan: 50,000hours
Color: RGB colorful and from warm white to cold white
Optics
Beam angle: 120degree
Dimmer: 0~100% linear dimmer
Light Output
CRI(white): Ra≥95
Color temperature: 3200k-5600k adjustable
Control
DMX channel: 7CH,7CH, 4CH
Control mode: DMX-512, Demo mode, Manual
Control panel: LCD display + 4 buttons
Power Supply
Related voltage: AC100V-240V, 50/60Hz
Related power: 150W
Construction
Body dimension: D730*W347*T153mm
Net weight: 7.5kg
Shell color: black
Housing material: aluminum alloy
Working Environment
Working temperature: -25-40℃
Cooling: aluminum radiator and light body
Protection rating: IP20
Spare Parts
Cable: 1set DMX in and DMX out signal cable, and 1set Power in and Power out power cable with plug [standard configuration]
Light visor: 1pc light visor [optional configuration]
Package
Carton board box package size: 810*520*250mm(1pc/carton) [c:19-11-19]
N.W/G.W/V.W: 9kg/11.7kg/21.1kg
Selling Maintain Spare Parts List
Switching power supply: Color Panel 1440G-P
LED lamp board: Color Panel 1440G-L
Main board: Color Panel 1440G-M
Drive board: Color Panel 1440G-D
