150W LED Moving Head Spot Light

-Model: VG-LM150S
-Color: 7 colors +white
-Beam angle: 15°
-Strobe: 1-25 times/second
-Power: 250W
  • VG-LM150S
  • VG-LM150S
  • 2016-12-29
  • Selling

  • We have designed this new item 150W led moving head spot light to meet the market need, this light is very good for night bar, stage, TV, and other entertainment place.


  • 150W High Output White LED

  • 50,000 hours lifespan and low power consumption

  • Temperature protect function, when the internal Temperature is up to 40° and ·then the fans begin to work, when the internal temperature is up to 70°and the brightness reduce half.

  • High speed strobe effect with 1-25 flashers per second

  • Internal program available

  • 16/14/12/10 DMX Channels USITT DMX-512

  • DMX 512, master-slave and sound activated controllable or auto operation

  • Colorful LCD display

  • Efficient low noise fan cooling system


  • 3-pin XLR connectors IN/OUT

  • Two 1/4 turn fastening Omega Clamps

  • IP 20 protection rating.

Technical Specifications

Light Source

  • LEDs: 1pc 150W white color led lamp

  • Color: white

  • Service life: 50000h

Optical System

  • Beam angle: 15°, focus function

  • High light output, 3450LUX@5M at White light

Electromechanical Effects

  • Color Wheel: 7 colors +white, rotation with variable direction and speed

  • 1 static Gobo Wheel: 8 gobos +white, wheel rotation and shake

  • 1 Rotation Gobo Wheel: 6 gobos +white, wheel rotation and shake

  • Prism: 3-facet Prism, bi-directionally rotatable at variable speeds

  • Dimmer: linear dimmer 0-100%

  • Strobe: 1-25time/s

  • Pan: 540°

  • Tilt: 270°

Control and Programming

  • Control mode: DMX-512; Master/slave mode; Demo mode; Sound active·

  • DMX channel: 16CH, 14CH, 12CH, 10CH

Thermal Specification

  • Maximum ambient temperature: 45 °C (113 °F)

  • Maximum surface temperature: 170 °C (338 °F)

Electrical Specification

  • Power supply: Electronic auto-ranging

  • Input voltage range: AC90-240V, 50/60Hz

  • Power consumption: 250W

Mechanical Specification

  • Light size: 270Dx270Wx470Hmm

  • Weight: 11.5kg

  • Material: ABS

  • Appearance color: black

Using Environment

  • IP rating: IP20

  • Working temperature: -25-40℃

  • Cool system: Fan

Standard Accessories Light

  • 1pc DMX cable

  • 1pc power cable

  • 1pc English version user manual

  • 1pc clamp bridge

Optional Accessories Light

  • Safety cable: choose the model which you need, chargeable

  • Clamps: choose the model which you need, chargeable

  • Flight case: choose the quantity which need pack, chargeable


  • Carton: 37*30*54cm(1pcs/carton) 【Confirmed on 2019-12-20】

  • N.W/G.W/V.W: 12kg/14kg/12kg

  • Flight case: 66*41*68cm(2pcs/case) [c: 19-12-03]

  • N.W/G.W: 26kg/46.9kg

  • Flight case: 75*67*66cm(4pcs/case) [f:18-01-03]

  • N.W/G.W: 44kg/81kg

Selling Spare Parts List

  • Switching power supply: VG-LM150S-P

  • LED lamp board: VG-LM150S-L

  • Main board: VG-LM150S-M

  • Drive board: VG-LM150S-D


Download Technical Specification Sheet

Download User Manual

 Download .R20 library for pearl series console

 Download .d4 library for Titan

 Download .XML libray for MA   16CH
